Powermax 45 XP
|
|
The Powermax45® XP plasma cutter delivers increased cut capacity – up to 16 mm (5/8″) metal – as well as faster cut speeds, and automatic gas adjustment for quick, simple setup and operation. Duramax® Lock torches support handheld and mechanized cutting of a wider range of metal thicknesses, along with precision gouging such as spot weld removal, and marking capabilities.
|
 |
| Technical Specification |
|
|
| Capacity |
Thickness |
Cut speed |
| Cutting |
| Recommended |
16 mm (5/8") |
500 mm/min (20 ipm) |
| |
22 mm (7/8") |
250 mm/min (10 ipm) |
| Severance (hand cutting) |
29 mm (1-1/8") |
125 mm/min (5 ipm) |
| Pierce |
12 mm (1/2") |
|
| Pierce rating for handheld use or with automatic torch height control |
|
|
| Capacity |
Metal removal rate |
Groove profile |
| Typical gouge |
3.4 kg/hr
(6.2 lbs/hr) |
3,2 mm D x 6.8 mm W
|
|
|
| |
|
| |
|
 |
|
