Powermax 85





The premier system for cutting 1" (25 mm), the Powermax85 has the same features and options as the Powermax65, but with more power from a max output current of 85 amps. A variety of Duramax torch styles provide exceptional versatility for hand cutting or gouging, portable automation, X-Y table and robotic cutting or gouging.














Technical Specification

Capacity Thickness Cut speed
Cutting
Recommended 25 mm (1") 500 mm/min (20 ipm)
  32 mm (1-1/4") 250 mm/min (10 ipm)
Severance (hand cutting) 38 mm (1-1/2") 125 mm/min (5 ipm)
Pierce 20 mm (3/4")
Pierce rating for handheld use or with automatic torch height control
Capacity Metal removal rate Groove profile
  Gouging
Typical gouge 8,8 kg/hr
(19.5 lbs/hr)
5,8 mm D x 7,1 mm W
(0.23" D x 0.28" W)
