Powermax 105





The Powermax105 delivers superior cut capabilities on 1-1/4" (32 mm) thick metals. It has the duty cycle and industrial performance necessary for tough cutting and gouging jobs. Seven Duramax torch styles provide versatility for hand cutting, portable automation, x-y table cutting, and robotic cutting and gouging. Smart Sense™ technology automatically adjusts the gas pressure according to cutting mode and torch lead length. It also detects electrode end-of-life, automatically turning off power to the torch to prevent potential damage to other parts or to the workpiece.






Technical Specification

Capacity Thickness Cut speed
  Cutting
Recommended 32 mm (1-1/4") 500 mm/min (20 ipm)
  38 mm (1-1/2") 250 mm/min (10 ipm)
Severance (hand cutting) 50 mm (2") 125 mm/min (5 ipm)
Pierce 22 mm (7/8")
Pierce rating for handheld use or with automatic torch height control
Capacity Metal removal rate Groove profile
  Gouging
Typical gouge 9,8 kg/hr
(21.7 lbs/hr)
6,4 mm D x 7,4 mm W
(0.25" D x 0.29" W)
